2023 Moonen 110 Mustique

This long-range Dutch-built steel yacht is available for immediate delivery.

This brand-new Moonen 110, is the latest creation of the Dutch shipyard's semi-custom range. The 34m long-range steel motor yacht offers grace and comfort, and recaptures the impeccable quality and proven ocean-going performance of past generations of Moonen yachts with more space, future-proof technology and more economical operation.

The Moonen 110 is a modern interpretation and evolution of the sought-after Moonen 84 and 97 designs. For this build, Moonen partnered with London-based interior architects Studio Indigo, to create a modern concept with a subtle nod to the shipyard's heritage.

Within her 7.5m beam, she offers accommodation for up to 10 guests in five luxurious ensuite staterooms, including a full-beam master suite on the main deck, with panoramic views over the bow. Comfortable accommodation for up to 5 crew members is divided into three ensuite cabins.

This vessel features a full displacement steel hull and aluminium superstructure, is outfitted with the most reliable equipment, and provides a transatlantic range of 3500 nautical miles at 9 knots. One of her key features is her capability of a very economical operation as low as 60 litres per hour, offering a very quiet, smooth and stable performance.

Specifications

Year Built 2023

Category Power

Length Overall 111'8 ft / 34.04 m

Beam 24'7 ft / 7.5 m

Max Draft 6'7 ft / 2 m

Cabins 5

Cabin Headroom 7'1 ft / 2.15 m

Electrical System 220v

Construction Steel

Drive Type Direct

Engines 2

Total Engine Power 1,199 hp

Cruising Speed 10 kn

Maximum Speed 13 kn

Range 4,027.73 mi

Fuel Tank Cap. 27,600 L

Water Tank Cap. 6,650 L

Holding Tank Cap. 2,000 L

Tax Status Not Paid

Engine 1 Specifications

Make: CATERPILLAR

Model: C-18 ACERT

Fuel: Diesel

Engine Power: 447kW

Type: Inboard

Engine Location: Port

Drive Type: Direct

Year: 2023

Engine 2 Specifications

Make: CATERPILLAR

Model: C-18 ACERT

Fuel: Diesel

Engine Power: 447kW

Type: Inboard

Engine Location: Starboard

Drive Type: Direct

Year: 2023

Specification

CONSTRUCTION:
Material hull: Steel Grade A
Material superstructure: 5083H111 for plates and 6082T6 for profiles
Stainless Steel: AISI316

DIMENSIONS:
Length overall: 34.04 metres (111’ 68”)
Length waterline: 31.17 metres (102’ 26”)
Beam overall: 7.50 metres (24’ 60”)
Beam waterline: 7.35 metres (24’ 11”)
Draught max : 2.00 metres (6’ 56”)
Gross Tonnage: 279 GT

TANKAGES:
Fuel: 27,600 litres (7,300 US gallon)
Fresh water: 6,650 litres (1,750 US gallon)
Waste water: 950 litres (250 US gallon)
Used lube oil: 350 litres (90 US gallon)
Clean lube oil: 350 litres (90 US gallon)
Grey water: 1,000 litres (265 US gallon)
Black water: 1,000 litres (265 US gallon)

PROPULSION & PERFORMANCE:
Main engines: 2 x Caterpillar C18 ACERT
Power rating: A-rating, each 447 bkW (600 bhp) at 1800 rpm
Transmission: Twin Disc
Cruising: 10 knots at 50% load and 85% RPM
Range: 3,500 nautical miles at 9 knots (economical speed)

NAVIGATION & COMMUNICATION EQUIPMENT:
VHF DSC – Class A
VHF DSC – Class D
Handheld VHF including GMDSS
Handheld UHF ATEX
V-Sat system
Inmarsat C system
MF/HF system
Wireless Computer Network
Internal Telephone System
Radar
ECS System
GPS
AIS
Wind, speed & depth log
Autopilot
BNWAS
Navtex

HOUSEHOLD APPLIANCES:

Lower deck:
Wash machine
Dryer
Refrigerator

Main deck:
Refrigerator
Fridge/Freezer
Oven
Dishwasher
Exhaust Hood
Cooking plate
Microwave

Bridge deck:
BBQ Grill
Refrigerator
Icemaker

> MORE DETAILS ON REQUEST <

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
